PCX Features :

·One unit machine cover an area of 35mآ²
·Screen control/ bottom control
·Maximum car picking time  60s
·Each unit are  separate.various combination forms
·Economic,good for design and management
·Low ventilation requirement.
·power consumption is 35% of the regular underground garage.




Specification:

· Layers:5~9. Car parks :8~16
· Car size:5200/5300*1900/1950*1700/2000
· Weight :2350kg
· Drive mode:electrical drive or chain traction
· Electric power :9.2 KW/11KW
· Frequency:380V/50Hz
· Noise:<65db
